  • Piezoelectric-based MEMS devices for sensor (chemical and biological detection) and actuator application (electrical switch).
  • Novel MEMS/NEMS devices using smart materials
  • Understanding electromechanical properties of ferroelectric and piezoelectric thin films and nano-structures: double-beam laser interferometer, piezoelectric scanning probe microscopy, time-resolved synchrotron X-ray scattering method, near-field optical microscopy.
  • Functional oxide nanoscale-structures and fabrication (e-beam lithography, dip-pen, modified chemical solution process)
  • Integrated high-K ferroelectric capacitors for high power electronic system and tunable devices.
  • Thin film deposition with sputtering (rf, dc, ion-beam), chemical vapor deposition, evaporation (e-beam and thermal), chemical solution deposition (sol-gel and MOD); characterization of thin films with various structural and electrical measurement techniques as well as computer automation.
  • Development of micro/nanofabrication processes for advanced devices.



Denton Sputter System

JEOL 5200 STM/AFM


Vibration Generator


Spin Coater

Environmental Probe Station

JEOL 7000 FE-SEM

STS AOE RIE System

JEOL 2100 TEM

RTP AG Heatpulse 610

Fotonic Sensor

Silicon Wafer Wet Etching System


Agilent 4294A Impedance Analyzer

CHA Mark 50C e-beam Evaporator

Double-side Aligner
